Electrodepot 40 Amp 12 Pole (4 Pole x 3) Normally Open, 110-120VAC Coil (Silent Operation), Motor Load 40A and Lighting Load 63A Contactor Bundle with 8" DIN Rail and 2 Number 10 Screws

ABOUT CONTACTOR40 Amp 12 Pole Normally Open Contactors (4 Pole x 3) for home or industrial uses.With applications in lighting, motor and switching.Technical Specifications:– Contactor IEC 400V– Contactor Type NO– Inductive Load: 40A– Resistive Load: 63A– DC Load: 30A, @ 24VDC– Power status indicator– Number of Poles 4 x 3– Coil Volts: 110/120VAC, 50/60 Hz– Coil Load: Inrush 52VA, Sealed 10VA– IEC AC Rate: AC-1, 10 kW. AC-3, 8 kW– Electric e strength: 4 kV– Operating Temperature: -30…+70 °C (-22…+158 °F)– 1 HP @ 1 Phase - 120V– 2 HP @ 1 Phase - 230V– 5 HP @ 3 Phase - 208V– 5 HP @ 3 Phase - 230V– 10HP @ 3 Phase - 480V– Weight: 0.88 lb (0.42 kg)– Width: 2.1" (54 mm)– Height: 3.3" (84 mm)– Depth: 2.5" (64 mm)– CE approved 61095, UL pending– Base or DIN 35mm mountWiring:Solid Conductor: 25 mm2 Max torque 0.6 NmStranding Conductor: 16 mm2, Max torque 0.6 NmCompliance:CSA C22.2 No. 14, EN 60947-4-1, EN 60947-5-1, IEC 947-2, IEC 60947-4-1, IEC 60947-5-1, UL 508ABOUT DIN RAILDIN Rails are the standard mounting support for any electromechanical component, device or equipmentdesigned using the DIN specifications adopted by European (EN) and international (IEC) standards.The rail features slots throughout its length making it easy to attach to a panel, wall or equipment.For support of mini circuit breakers, contactors, auxiliary relays, terminal blocks, low voltage apparatuses, etc.– Width: 35mm (1.375”)– Length 200mm (7.87”)– Thickness 5mm (0.2”)ABOUT SCREWSDrive stainless steel truss head screws (#10, 1/2"") for immediate installation.

• BUNDLE CONTENT: 6 ITEMS – Three (3) 40A 4 Pole Normally Open (NO) Contactors with power status indicator; one (1) compatible Slotted Steel Zinc Plated 35mm x 200mm DIN Rail and two (2) stainless steel truss head screws (#10, 1/2") for immediate home or industrial installation
• CONTACTOR APPLICATIONS – Lighting, motor or switching. AC-1 for resistance furnaces, incandescent lamps or electric heaters; and AC-3 for air conditioners, compressors or fans. 24/120/220/277 V, with an energy saving, silent and no humming coil
• COIL VOLTAGE AND LOAD – Contactor IEC 400V. Coil Voltage 110/120VAC, 50/60 Hz; Coil load Inrush 52VA, Sealed 10VA. Inductive/Motor Load: 40Amp, Resistive/Incandescent Load: 63Amp. DC Load: 30Amp @ 24VDC. Compatible with 15 Amp, 20 Amp, 30 Amp, 32 Amp, 40 Amp, 50 Amp, 60 Amp and 63 Amp loads. Power Lug Terminal Capacity AWG # 4
• OTHER CONTACTOR DETAILS – Contactor type NO with 4 poles, power status indicator. IEC AC Rate: AC-1; 10 kW, AC-3; 8 kW. Electric e strength: 4 kV. Operating Temperature -30…+70 °C (-22…+158 °F). Dimensions (approx.): 54 x 64 x 84 mm / 2.1'' x 2.5'' x 3.3'' (Length x Width x Height)
• DIN RAIL – Standard mounting support for any electromechanical component, including contactors, using the DIN specifications adopted by European (EN) and international (IEC) standards. Standard width 34.9mm (1.375”) length 200mm (7.87”) and thickness 5mm (0.2”).
